Glacier Coolant LM-15A Modified Polysiloxane Heat Transfer Fluid -70°C to 180°C

short description:

✦ Glacier Coolant LM-15A is a professional-grade refrigeration fluid designed for indirect cooling systems. It efficiently transfers cooling capacity to target media and is widely applied in chemical, pharmaceutical and other industrial fields.

Product Brand: Glacier Coolant

Product Model: LM-15A

Product Character: Light color or colorless liquid.

Product Composition: LM-15A Glacier Coolant is composed of modified polysiloxane.

Send email to us

Product Detail

Product Tags

Main parameters

Glacier Coolant LM-15A is insoluble in water, has low freezing point, high flash point, stable chemical properties, good hydrophobicity and long service life. It has almost no adverse effects on many materials represented by metals and is suitable for long-term use in the temperature range of -70℃~180℃. At 20 ℃, the density, viscosity, thermal conductivity and specific heat of Glacier Coolant LM-15A are 0.919 g/cm3, 5.63 cP, 0.1257 W/m·K and 1.7506 kJ/kg·K, respectively. The boiling point of Glacier Coolant LM-15A is higher than 200℃, and the freezing point is less than -70℃. It is suitable for water sensitive anhydrous systems.

Physical parameters (reference value)

Temperature (℃)	Density	Viscosity	Specific heat	Thermal conductivity
Temperature (℃)	(g/cm³)	(mPa·s)	(kJ/kg·K )	(W/m·K)
20	0.919	5.63	1.7506	0.1257
0	0.937	8.20	1.7282	0.1289
-20℃	0.961	13.16	1.7006	0.1327
-40℃	0.980	23.80	1.6788	0.1359
-70℃	1.009	86.79	1.6543	0.1392

Product Features

◈ Outstanding thermal stability with extended service life
◈ Suppresses liquid volatilization to lower overall consumption
◈ Physiologically inert with superior biological safety
◈ Broad operating temperature range, excellent high and low temperature resistance
◈ Premium dielectric properties and outstanding wetting capability
◈ Excellent hydrophobicity and high dispersion performance

Compatibility of non-metallic materials

The compatibility between non-metallic materials and Glacier Coolant LM-15A is as follows:

Material	EPDM	PTFE	HDPE	PP	Natural rubber	Silicone rubber
LM-15A	√	√	√	√	√	×

Note: The symbol "√" indicates no dissolution, swelling, aging or other abnormal phenomena. Please consult our technical staff for compatibility with other materials.

Usage Method

Under high-temperature conditions, LM-15A is susceptible to contamination from strong acids, strong bases, certain metal compounds, and oxidants. These contaminants can speed up the formation of volatile by-products, while oxidants may also lead to a rise in product viscosity. When such conditions are possible, it is advisable to regularly inspect the product’s flash point to ensure operational safety. Furthermore, if the liquid releases smoke, there may be flammable conditions present.
1. LM-15A must be used independently and should not be mixed with other secondary refrigerants or heat transfer media. In the event of special circumstances, please contact our company promptly.
2. After confirming that there are no leakage points in the system, clean the system and drain all water. Once the system is dried, add the glacier coolant solution to it as soon as possible.
3. It is recommended that the system be operated in a closed mode, and a nitrogen sealing device should be installed to prevent moisture from entering the system during use.

Storage and usable life

This product may degrade due to factors such as heat, light, acids, and alkalis, so it should be stored in a sealed container in a cool place. When kept in the original unopened containers at a temperature of 25°C or below, the product has a usable life of 30 to 60 months from the date of production, depending on its viscosity.

After-sale service and testing items

Relevant staff will provide tracking services during the product’s usage. They will regularly collect samples of the products used by customers and bring them back to the company for testing. The testing items are conducted in the company’s low-temperature liquid heat transfer medium engineering laboratory in accordance with the company’s testing standards. The testing items are as follows:
1. Specific heat capacity test: To ensure the cold-carrying capacity of the glacier coolant;
2. Thermal conductivity test: To ensure the thermal conductivity of the glacier coolant;
3. Low-temperature viscosity test: To ensure the working efficiency of the glacier coolant;
4. Boiling point and freezing point tests: To ensure that the operating temperature range of the glacier coolant meets the standard;
5. High-temperature corrosion protection test: To ensure the product’s corrosion resistance under extreme conditions.
Test reports will be promptly fed back to customers. In case of any problems, we will provide solutions and cooperate with relevant technical services to deliver 360-degree all-round after-sales service to customers.

Notes

For specific requirements and safety precautions regarding the operation, use, and storage of the glacier coolant, please refer to the product’s safety technical manual, safety label, enterprise standards, and other related information. Please read these materials carefully before using this product.
